Csendőr
( )

Ship name:Hajnal II. (Ex Foktő)
Ship category:Motor pleasure yachts
Name of class:Csendőr
Construction:Steel

Project's details:

Project name:Calculations of hydrostatics
Project description:Calculation of hydrostatics and initial stability characteristics of a motor craft.

Applied rules/registers:

KöViM Rules for Design, Construction and Conformance of Pleasure Boats

Main features:

Length overall, Lbef [m]12
Maximum length, Lmax1 [m]12
Maximum length of hull, Lmax2 [m]12
Waterline length, Lwl [m]10,781
Maximum breadth with fender rail, Bmax [m]3,2
Breadth of hull, b [m]3
Waterline breadth, Bwl [m]2,807
Depth, D [m]2,2
Freeboard, f [m]1,1
Lightship, delta0 [t]7,1
Deadweigth, deltamax [t]9,17
Draugth with propulsory equipment, centerboard and keel, Tk [m]1,02
Inbuilt engine power rating, N [kW]108
Service speed, v [km/h]17
Crew, n11
Maximum passenger capacity, n2 [fő]11
Maximum load [kg]1020
CE classification of design categoryB
Type of main engine1 Mercedes-Benz D124
Character of main engineDiesel
Continuous service raing [LE]1x145

Ship engineer tasks:

Calculation of hydrostatics
Buoyancy and stability check
