« Motor ships

Primőr 18
( PR18-000-000 )

Ship name:Tanár Úr
Name of class:Primőr 18

Project's details:

Project number:PR18-000-000
Project name:ISO 12217-3 szerinti vizsgálatok és döntéspróba

Main features:

Length overall, Lbef [m]5,7
Maximum length, Lmax1 [m]5,45
Maximum length of hull, Lmax2 [m]5,45
Waterline length, Lwl [m]4,7
Maximum breadth with fender rail, Bmax [m]2,17
Breadth of hull, b [m]2,17
Waterline breadth, Bwl [m]1,64
Depth, D [m]0,976
Freeboard, f [m]0,454
Airdraft from baseline, Hfix [m]1,82
Lightship, delta0 [t]990
Deadweigth, deltamax [t]1370
Maximum hull draugth, Th [m]0,489
Service speed with machinery, v [kts]40-45
Fuel [kg]44
Crew, n11
Maximum passenger capacity, n2 [fő]3
Maximum load [kg]312
CE classification of design categoryC or D
Continuous service raing [LE]130

Ship engineer tasks:

Inclining experiment documentation
