Gravel production
( 3B-III-010-000 )

Name of floating machine:FŐTE 500 T/H 3B II
Floating machine category:Floating belt conveyor for dredger
Type of purpose:Gravel production

Project's details:

Project number:3B-III-010-000
Project name:Complementation of 3B II documentation of FÖTE Mining and Supplier Ltd. grab dredger's belt conveyor

Applied rules/registers:

Technical supervisory regulations for inland ships
A belvízi utakon közlekedő úszólétesítmények hajózásra alkalmassága és megfelelősége feltételeiről, az úszóképesség vizsgálatáról és tanúsításáról szóló 13/2001. (IV.10.) KöViM rendelet.

Main features:

Length overall, Lbef [m]106,7
Maximum length, Lmax1 [m]106,7
Maximum length with fender rail, Bmax [m]6,13
Maximum breadth, Bmax [m]6
Waterline breadth, Bcw1 [m]6
Depth, D [m]1,25
Freeboard, f [m]0,39
Airdraft from baseline, Hfix [m]4,6
Lightship, delta 0 sz [t]6,9
Maximum displacement, delta maxsz [t]75
Maximum lightship draugth, Tk [m]0,7
Crew, n1 [fő]2

Ship engineer tasks:

Technical description
General arrangement, general structure design
Technical description of electrics
Detail calculations according to 13/2001. / II. / 17. regulation
Subdivision and damage stability calculations
Strength analysis
Safety equipments
Instruction manual
