FAJTA8M
( )

Ship category:Motor pleasure yachts
Name of class:FAJTA8M
Construction:Glass Reinforced Plastic

Project's details:

Project name:Leasure motor craft specific approval project documentation
Project description:Calculation of hydrostatics and initial stability characteristics of a motor craft.

Applied rules/registers:

KöViM Rules for Design, Construction and Conformance of Pleasure Boats

Main features:

Length overall, Lbef [m]7.95
Maximum length, Lmax1 [m]7.95
Maximum length of hull, Lmax2 [m]7.95
Waterline length, Lwl [m]7.2
Maximum breadth with fender rail, Bmax [m]2.5
Breadth of hull, b [m]2.5
Waterline breadth, Bwl [m]2.1
Depth, D [m]1.4
Freeboard, f [m]0.78
Lightship, delta0 [t]1.6
Deadweigth, deltamax [t]2.5
Mean draugth without speed [m]0.4
Crew, n11
Maximum passenger capacity, n2 [fő]7

Ship engineer tasks:

Calculation of hydrostatics
Weigth and stability calculation
Buoyancy and stability check
